Servo Positioning
Servo side alignment provides positioning accuracy up to +/-0.1mm.
Edge Banding Machine
HK680 Full Servo Edge Banding Machine
A full servo edge banding machine for panel furniture factories, with servo-controlled alignment, pressure beam, pressing, edge feeding, trimming, tracking and scraping.
Full Servo Control
Servo Pressure Beam
Servo Edge Feeding
Servo Dual Position Tracking
Servo Edge Scraping
Built for Demanding Panel Furniture Production
Multiple servo systems control key processing units, reducing manual setup while improving edge banding stability and consistency.
- Suitable for continuous, high-output edge banding
- Processes cabinet panels, door panels, filler panels and narrow panels
- Rapid adjustment for different panel thicknesses
Core Features
Servo positioning, rapid adjustment and stable pressing deliver consistent, clean edge banding.
Servo Pressure Beam
Rapid height adjustment accommodates different panel thicknesses with less downtime.
Servo Pressing and Feeding
Servo-controlled pressure rollers and edge feeding improve bonding stability and reduce deviation.
Servo Trimming and Scraping
On-screen tool positioning produces smooth, clean upper and lower edges.
Servo Dual Position Tracking
Two coordinated servo systems improve tracking synchronization and stability.
Continuous Production
An 18-26m/min feed speed supports daily batch production.
Key Structures and Technology
Servo Side Alignment
Precisely adjusts the fence position with accuracy up to å¤0.1mm.
Servo Pressure Beam Lifting
Precisely controls beam height for fast panel thickness changes.
Pre-Milling
Diamond twin cutters and inlet dust blowing produce a flatter panel edge.
Gluing and Edge Banding
A pneumatic glue pot applies adhesive evenly for a fine glue line.
Servo Pressing
Four independent servo-controlled rollers provide dynamic pressing and fast thickness adjustment.
Front and Rear End Trimming
Independent high-frequency motors and linear guides remove end excess quickly and accurately.
Servo Fine Trimming
On-screen tool adjustment trims excess edge material into a smooth radius.
Servo Dual Position Tracking
Two servo systems coordinate tool and feed positions for synchronized processing.
Servo Edge Scraping
Four servos dynamically position the tools for smooth upper and lower edges.
Rigid Flat Scraping
Removes surface glue residue for a flatter, cleaner panel edge.
Polishing
High-speed twin polishing wheels clean the edge for a smoother finish.
Applications
HK680 supports a range of edge banding applications in panel furniture production.
Cabinet Production
Edge banding for kitchen cabinets, base cabinets and cabinet panels.
Furniture Production
Stable edge banding for batch panel furniture production.
Door Production
Edge processing for door panels and decorative panels.
Panel Processing
Processes filler panels, top cabinet panels, rails and narrow panels.
Edge Banding Result
Technical Specifications
Specifications are subject to the actual machine and final confirmed configuration.
| Model | HK-S680 |
|---|---|
| Machine Type | Full Servo Edge Banding Machine |
| Overall Dimensions | 6600*745*1650mm |
| Machine Weight | 3T |
| Panel Thickness | 9-60mm |
| Edge Band Thickness | 0.4-3mm |
| Minimum Workpiece Length | >=150mm |
| Minimum Workpiece Width | >=100mm |
| Feed Speed | 18-26m/min |
| Total Power | 20kW |
| Conveyor Motor Power | 4kW |
Suitable Users
Panel furniture factories, custom furniture factories, door panel processors and continuous edge banding operations.
Processing Applications
Top cabinet panels, filler panels, kitchen cabinets, base cabinets, corner strips and narrow panels.
Configuration Note
Specifications may change and are subject to the actual machine and final confirmed configuration.
Factory Strength
Factory Exterior
Factory exterior view.
Six-Sided Drilling Workshop
Mainly produces six-sided drilling machines and production lines.
CNC Cutting Workshop
Mainly produces CNC cutting machines and cutting lines.
Edge Banding Workshop
Mainly produces small and large edge banding machines.
Shanghai Exhibition Site
Team photo at the exhibition.
Foshan Lunjiao Exhibition Site
Team photo at the exhibition.
FAQ
What type of machine is the HK680?
HK680 is a full servo edge banding machine for panel furniture production.
Who is the HK680 designed for?
It is suitable for panel furniture factories, custom furniture factories, door panel processors and continuous production users.
What is the feed speed?
The specified feed speed is 18-26m/min.
What panel thickness can it process?
The specified panel thickness range is 9-60mm.
What edge band thickness can it use?
The specified edge band thickness range is 0.4-3mm.
What is the minimum workpiece size?
The minimum length is >=150mm and the minimum width is >=100mm.
What does servo pressure beam lifting do?
It precisely controls beam height and rapidly adapts to different panel thicknesses.
What is the purpose of servo edge feeding?
It controls edge band speed and position to reduce stretching and deviation.
What does servo dual position tracking do?
Two servo systems coordinate tool and feed positions for synchronized processing.
What is the purpose of servo edge scraping?
Four servos control tool positions to produce smoother, cleaner upper and lower edges.
Can the HK680 process narrow panels?
Yes. It supports narrow panel edge banding and other panel furniture edge processing applications.
What are the production lead time and warranty?
The production lead time is 30 working days and the warranty period is one year.
