Pre-Milling
Pre-trims the panel edge to remove waves, burrs, and slight unevenness, creating a straighter base for glue application and edge banding.
Edge Banding Machine
HK-568 Heavy-Duty Automatic Edge Bander
The HK-568 is a heavy-duty automatic edge banding machine designed for batch production of panel furniture. It covers pre-milling, glue application, edge banding, end trimming, rough and fine trimming, corner tracking, scraping, flexible scraping, cleaning, and double polishing, making it suitable for cabinet panels, doors, shelves, and narrow panel edge banding.
Heavy-Duty Automatic Edge Banding
Inovance Electrical Control System
Independent Upper Glue Pot
Six-Roller Pressing
Flexible Scraping + Cleaning
Built for High-Intensity Edge Banding Production
The HK-568 uses a heavy-duty semi-enclosed frame, an Inovance PLC and inverter control system, Haisen small pressure wheel chain blocks, and an independent upper glue pot. It helps furniture factories improve edge banding stability, processing accuracy, and long-term operating reliability.
- Suitable for narrow panels such as top cabinet cover panels, closing panels, front and rear cabinet rails, and base cabinet corner strips.
- The pneumatic glue pot works with six-roller pressing for stronger bonding and a finer glue line.
- Flexible scraping, cleaning, and double polishing reduce glue residue and improve edge surface smoothness.
Structure and Process Modules
The process sequence covers pre-milling, glue application and edge banding, end trimming, rough + fine trimming, corner tracking, scraping, flexible flat scraping + cleaning, and double polishing.
Glue Application and Edge Banding
The upper glue pot applies glue evenly, while the pressing unit bonds the edge band to the panel for a finer glue line and stronger adhesion.
End Trimming
Cuts and trims the excess edge band at the front and rear ends of the panel, keeping the ends flush and reducing manual finishing.
Rough + Fine Trimming
Rough trimming removes excess edge band from the upper and lower edges, while fine trimming shapes a smoother and more consistent edge profile.
Corner Tracking
Tracks and trims panel corners to improve corner transitions and create a more natural, refined edge banding result.
Scraping
Removes fine cutter marks and remaining edge band material after trimming, leaving the upper and lower edges smoother and cleaner.
Flexible Flat Scraping + Cleaning
Flexible flat scraping removes glue residue along the joint, while the cleaning process clears remaining adhesive and debris for a cleaner surface.
Double Polishing
Double polishing finishes the edge banding surface, improving smoothness and the final appearance of the panel edge.
Application Scenarios
Suitable for panel furniture factories, cabinet workshops, narrow panel edge banding, and production capacity upgrades.
Cabinet Production
Used for edge banding cabinet side panels, shelves, base cabinets, and furniture components.
Narrow Panel Edge Banding
Suitable for top cabinet cover panels, closing panels, front and rear cabinet rails, and base cabinet corner strips.
Panel Furniture
Designed for edge banding in batch panel furniture production.
Workshop Upgrade
Improves edge banding speed, processing consistency, and production rhythm.
Edge Banding Result
Technical Specifications
Final specifications are subject to the physical machine and confirmed proposal.
| Model | HK-568 | Overall Dimensions | 7300*1000*1650mm |
|---|---|---|---|
| Tracking Feed Speed | 22m/min | Edge Band Width | 10-60mm |
| Polishing Motor Power | 0.18KW*4 | Machine Weight | 3T |
| Conveyor Motor Power | 5.5KW | Edge Band Thickness | 0.4-3mm |
| Pre-Milling Motor Power | 2.2KW*2 | Total Power | 15KW |
| End Trimming Motor Power | 0.3KW*2 | Rated Voltage | 380V 50HZ |
| Rough Trimming Motor Power | 0.75KW*2 | Minimum Workpiece Length | ≥150mm; tracking ≥200mm; short edge ≥45*200mm |
| Fine Trimming Motor Power | 0.75KW*2 | Rated Air Pressure | 0.7MPA-0.9MPA |
| Tracking Motor Power | 0.3KW*2 | Minimum Workpiece Width | ≥40mm |
| Glue Tank Heating Power | 1.8KW | Workpiece Feed Speed | 18-22-25m/min |
Machine Features
Key features include electrical control, narrow panel edge banding, independent glue application, stable conveying, a heavy-duty frame, and convenient polishing adjustment.
Inovance Electrical Control System
The machine uses an Inovance PLC and inverter control system for stable performance, strong functionality, and higher precision.
Narrow Panel Edge Banding
Suitable for top cabinet cover panels, closing panels, front and rear cabinet rails, and base cabinet corner strips.
Independent Upper Glue Pot
The standard pneumatic glue pot works with six-roller pressing for on-demand operation and a fine glue line.
Haisen Small Pressure Wheel Chain Blocks
Haisen small pressure wheels and chain blocks help keep panel conveying and edge banding stable and durable.
Heavy-Duty Semi-Enclosed Frame
The frame goes through aging, annealing, shot blasting, and five-axis machining to support precision and long-term stability.
Convenient Double Polishing
The patented sliding double-polishing design makes polishing wheel replacement and adjustment faster and easier.
Factory Strength
Factory Exterior
Exterior view of the SYUTECH factory.
Edge Banding Machine Workshop
Production area for small, medium, and large edge banding machines.
CNC Nesting Machine Workshop
Production area for CNC nesting machines and cutting line solutions.
Six-Sided Drilling Machine Workshop
Production area for six-sided drilling machines and line solutions.
Shanghai Exhibition
Exhibition team and machine display.
Foshan Lunjiao Exhibition
Exhibition team and machine display.
Frequently Asked Questions
Common questions about machine selection, delivery, operation, and after-sales service.
How long is the production lead time?
The standard production lead time is 30 working days. The final delivery schedule depends on order configuration, production planning, and shipping arrangements.
How long is the warranty?
The machine comes with a one-year warranty. The after-sales team can support installation, commissioning, operator training, and daily operation questions.
Which factories is this machine suitable for?
It is suitable for panel furniture factories, cabinet workshops, custom furniture manufacturers, and factories that need higher edge banding stability and capacity.
What panels can it process?
It is suitable for cabinet panels, doors, shelves, closing panels, narrow panels, top cabinet cover panels, front and rear cabinet rails, and base cabinet corner strips.
What is the edge banding tape range?
The edge band thickness range is 0.4-3mm, and the edge band width is 10-60mm.
What is the minimum panel size?
The minimum workpiece length is ≥150mm, tracking length is ≥200mm, short edge is ≥45*200mm, and the minimum workpiece width is ≥40mm.
What site conditions are required?
The rated voltage is 380V 50HZ, and the rated air pressure is 0.7MPA-0.9MPA. Please confirm factory voltage, air supply, and installation space before purchase.
What should be confirmed before purchase?
Please confirm panel specifications, edge band tape specifications, required capacity, optional configuration, delivery schedule, and the official quotation proposal.
