Inovance Control System
The electrical system uses Inovance PLC and inverters for stable performance, powerful control functions, long service life and higher control accuracy.
HK-468 Heavy-Duty Automatic Edge Banding Machine
HK-468 is designed for panel furniture factory production. It integrates gluing and edge banding, end trimming, rough trimming, fine trimming, corner tracking, scraping, flexible scraping, cleaning and polishing into one continuous edge banding workflow.
Inovance Control System
Independent Upper Glue Pot
Haisen Pressure Wheels and Chain Blocks
Heavy-Duty Enclosed Frame
SYUTECH Patented Easy Polishing
Heavy-Duty Automatic Edge Banding Solution for Panel Furniture Factories
With a heavy-duty frame and stable electrical control system, HK-468 is suitable for cabinet panels, top cabinet sealing panels, closing boards, front and rear pull strips, base cabinet corner lines and other panel edge banding tasks.
- One machine supports regular panels and narrow-panel end edge banding.
- Standard pneumatic upper glue pot works with six-wheel pressing for fine glue lines.
- The machine uses Inovance PLC and inverter control for stable operation and accurate control.
Machine Highlights
Key configurations include the electrical control system, narrow-panel edge banding, independent gluing, pressure wheel chain blocks, heavy-duty frame and convenient polishing design.
Narrow Panel Edge Banding
Suitable for top cabinet sealing panels, closing boards, cabinet front and rear pull strips, base cabinet corner lines and narrow-panel end edge banding.
Independent Upper Glue Pot
Standard pneumatic upper glue pot works with six-wheel pressing to improve edge banding efficiency, support quick use and produce fine glue lines.
Haisen Pressure Wheels and Chain Blocks
Haisen small pressure wheels and chain blocks help keep panel feeding and edge banding stable, durable and consistent.
Heavy-Duty Enclosed Frame
The frame provides strong rigidity and resistance to deformation, with welding followed by aging, annealing, shot blasting and precision machining.
SYUTECH Patented Easy Polishing
The double polishing unit uses a slider-style design, making polishing wheel replacement and adjustment simple and efficient.
Structure and Process Modules
The process covers gluing and edge banding, end trimming, rough trimming, fine trimming, corner tracking, scraping, flexible scraping, cleaning and polishing.
Gluing and Edge Banding
Pneumatic upper glue pot applies glue evenly with a fine glue line. The pressing unit combines steel wheels, rubber wheels and glue scraping support for firmer edge band adhesion.
End Trimming
Precision linear guide movement, profiling follow-up and high-frequency high-speed motor cutting trim the excess edge banding at the front and rear of the panel.
Rough Trimming + Fine Trimming
Rough trimming uses a high-frequency motor structure with large and small disc automatic tracking to remove excess edge banding. Fine trimming uses an R cutter to form an R arc edge.
Corner Tracking
Fast response, synchronized tracking trimming and high-speed corner chamfering finish all four corners in one pass for smoother and cleaner edge banding results.
Scraping
Scraping knives remove ripple marks caused by rotation on both sides of the edge band, matching the fine-trimmed R corner and making upper and lower edges cleaner.
Flexible Scraping + Cleaning
Flexible scraping removes excess glue squeezed from the upper and lower seams, reducing glue adhesion on polishing wheels. Cleaning sprays mist before polishing to remove hot-melt glue and chips.
Polishing
Two groups of high-speed polishing wheels clean the processed panel, making the edge banding surface smoother and more attractive while keeping wheel wear even.
Applications
Suitable for panel furniture production, cabinet processing and edge banding capacity upgrades.
Cabinet Production
Suitable for cabinet side panels, shelves, base cabinets and furniture components.
Panel Furniture
Supports stable edge banding for batch panel furniture production.
Workshop Upgrade
Helps improve edge banding speed, processing consistency and equipment workflow.
Production Line Support
Can work with cutting, drilling and cabinet production processes.
Edge Banding Result
Technical Specs
Final configuration is subject to the actual machine and official proposal.
| Model | HK-468 | Overall Dimension | 6100*1000*1650mm |
|---|---|---|---|
| Tracking Feed Speed | 22m/min | Edge Band Width | 10-60mm |
| Polishing Motor Power | 0.18KW*4 | Machine Weight | 2T |
| Conveyor Motor Power | 3KW | Edge Band Thickness | 0.4-3mm |
| End Trimming Motor Power | 0.3KW*2 | Total Power | 10kw |
| Rough Trimming Motor Power | 0.75KW*2 | Rated Voltage | 380V 50HZ |
| Fine Trimming Motor Power | 0.75KW*2 | Minimum Workpiece Length | >=150mm; tracking >=300mm |
| Tracking Motor Power | 0.3KW*2 | Rated Air Pressure | 0.7MPA-0.9MPA |
| Glue Pot Heating Power | 1.8KW | Minimum Workpiece Width | >=50mm |
| Workpiece Feed Speed | 18-22-25m/min | ||
Factory Strength
Factory Exterior
SYUTECH factory exterior and production base display.
Edge Banding Machine Workshop
Production area for small, medium and large edge banding machines.
CNC Nesting Machine Workshop
Production area for CNC nesting machines and cutting line solutions.
Six-Sided Drilling Workshop
Production area for six-sided drilling machines and production line solutions.
Shanghai Exhibition Site
Exhibition team and machine display.
Foshan Lunjiao Exhibition Site
Exhibition team and machine display.
FAQ
Common questions about HK-468 model selection, production use and optional configurations.
What type of machine is HK-468?
HK-468 is a heavy-duty automatic edge banding machine for panel furniture factory equipment solutions and continuous cabinet panel edge banding production.
What standard processes are included?
Standard processes include gluing and edge banding, end trimming, rough trimming, fine trimming, corner tracking, scraping, flexible scraping, cleaning and polishing.
Is it suitable for narrow panels?
Yes. It can be used for top cabinet sealing panels, closing boards, front and rear pull strips, base cabinet corner lines and narrow-panel end edge banding.
What edge band range does it support?
The edge band width is 10-60mm, and the edge band thickness is 0.4-3mm, suitable for regular panel furniture edge banding needs.
What workpiece size is required?
The minimum workpiece length is >=150mm, or >=300mm when tracking is used. The minimum workpiece width is >=50mm.
What optional configurations are available?
Optional items include laser edge banding, PUR single-color or dual-color glue machine with glue pot, quick glue melting device, heating lamp, edge band insulation box and narrow-edge end feeding device.
