Gluing and Edge Banding
Pneumatic glue on/off upper glue pot applies glue evenly with a fine glue line. The six-wheel pressing unit combines steel wheels, rubber wheels and glue scraper support to make edge banding adhesion firmer.
HK368 Automatic Edge Banding Machine
HK368 is positioned as a basic automatic edge banding machine for panel furniture, cabinet and regular furniture panel production. It covers gluing, end trimming, rough trimming, fine trimming, scraping, cleaning and polishing.
Basic Automatic Edge Bander
Upper Glue Pot Gluing
End Trimming
Scraping and Cleaning
Double Polishing
Basic Automatic Edge Banding Solution for Panel Furniture Factories
HK368 is designed for regular panel furniture edge banding production, focusing on stability, practical operation and easy factory adoption. It is suitable for furniture factories, cabinet workshops and production projects that need to improve edge banding efficiency.
- Suitable for cabinet panels, shelves, door panels and regular furniture panels.
- Covers core processes including gluing, end trimming, rough trimming, fine trimming, scraping, cleaning and polishing.
- Can serve as a basic configuration for upgrading from semi-automatic edge banding to automatic edge banding.
Structure and Process Modules
Covers gluing, end trimming, rough trimming, fine trimming, scraping, flexible scraping, cleaning and polishing processes.
End Trimming
Precision linear guide movement uses profiling follow-up and high-frequency high-speed motor cutting to trim excess edge banding at the front and rear ends of the panel.
Rough Trimming + Fine Trimming
Rough trimming uses a high-frequency motor structure with large and small disc automatic tracking to remove excess upper and lower edge banding. Fine trimming uses an R cutter to form an R arc edge.
Scraping
Scraping knives on both sides remove ripple marks caused by rotation on the edge band. The finished R corner matches fine trimming, making the upper and lower edges smoother and cleaner.
Polishing
Two high-speed polishing wheels clean the processed board, making the edge banding section smoother and more attractive while keeping polishing wheel wear even.
Applications
Suitable for panel furniture production, cabinet processing and edge banding capacity upgrades.
Cabinet Production
Suitable for cabinet side panels, shelves, base cabinets and furniture components.
Panel Furniture
Supports regular edge banding processes in batch panel furniture production.
Workshop Upgrade
Helps improve edge banding speed, stability and production continuity.
Production Line Support
Can work with cutting, drilling, cabinet production and other factory workflows.
Edge Banding Result
Technical Specs
Final configuration is subject to the actual machine and official proposal.
| Model | HK368 | Machine Type | Basic Automatic Edge Banding Machine |
|---|---|---|---|
| Overall Dimension | 4700*1000*1650mm | Machine Weight | 2T |
| Edge Band Width | 10-60mm | Edge Band Thickness | 0.4-3mm |
| Minimum Workpiece Length | >=150mm; tracking >=300mm | Minimum Workpiece Width | >=50mm |
| Workpiece Feed Speed | 18-22-25m/min | Total Power | 10kw |
| Rated Voltage | 380V 50HZ | Rated Air Pressure | 0.7MPA-0.9MPA |
| Conveyor Motor Power | 3KW | Glue Pot Heating Power | 1.8KW |
Factory Strength
Factory Exterior
SYUTECH factory exterior and production base display.
Edge Banding Machine Workshop
Production area for small, medium and large edge banding machines.
CNC Nesting Machine Workshop
Production area for CNC nesting machines and cutting line solutions.
Six-Sided Drilling Workshop
Production area for six-sided drilling machines and production line solutions.
Shanghai Exhibition Site
Exhibition team and machine display.
Foshan Lunjiao Exhibition Site
Exhibition team and machine display.
FAQ
Customer questions before model selection, purchase and production adoption.
What types of factories is HK368 suitable for?
It is suitable for panel furniture factories, cabinet workshops, custom furniture manufacturers and factories upgrading from semi-automatic to automatic edge banding.
What panel parts can it process?
It can be used for cabinet side panels, shelves, door panels, closing boards, top cabinet sealing boards, front and rear pull strips and other regular panel furniture parts.
What edge band range does it support?
The supported edge band width is 10-60mm, and the edge band thickness is 0.4-3mm, suitable for regular furniture panel edge banding needs.
How fast is the feed speed?
The workpiece feed speed is 18-22-25m/min. Actual efficiency depends on panel specifications, process requirements and the operator's production rhythm.
What standard functions are included?
The displayed core processes include gluing and edge banding, end trimming, rough trimming, fine trimming, scraping, cleaning and polishing.
What should be confirmed before purchase?
Confirm panel size, edge band specifications, voltage, factory space and whether optional items such as PUR or laser edge banding are required before finalizing the solution.
