Pre-Milling
Diamond double-cutter pre-milling with pneumatic front and rear feeding. It mills panel surface ripples and expanded edges to make the board edge flatter, with inlet dust blowing to reduce dust impact on edge banding quality.
HK268GY Compact Automatic Edge Banding Machine
HK268GY is a compact automatic edge bander designed for panel furniture, custom cabinet and small-to-medium workshop edge banding production. The lower machine body and compact layout help save workshop and shipping space while keeping the main edge banding processes integrated.
Compact Machine Body
Automatic Edge Banding
Stackable for Container Loading
Complete Edge Banding Flow
Workshop-Friendly Layout
Compact Edge Banding Solution for Space-Conscious Furniture Workshops
HK268GY combines compact dimensions with the core edge banding process. It is suitable for customers who need to reduce floor-space pressure, simplify installation and movement, and improve container loading efficiency.
- Compact machine size for panel furniture factories and custom cabinet workshops.
- Covers pre-milling, gluing, pressing, end trimming, fine trimming, tracking, scraping and polishing.
- Stackable for container loading, helping optimize shipping space for export projects.
Core Function Modules
Function details are organized from HK268GY materials, covering edge preparation, gluing and pressing, end trimming, fine trimming, corner tracking, scraping and polishing.
Gluing and Pressing Unit
The pneumatic glue pot applies glue evenly with a fine glue line. The pressing unit uses a multi-wheel pressing structure with steel wheel, rubber wheel and glue scraper support for firm edge band adhesion.
End Trimming
Precision linear guide movement, automatic profiling follow-up and high-frequency high-speed motor cutting trim the excess edge banding at the front and rear ends of the panel.
Fine Trimming
The R cutter performs round-corner trimming on the edge band, forming an R arc profile to improve the feel and visual finish of the board edge.
Corner Tracking
Fast-response synchronized tracking trims the corners at high speed. Four corners can be milled in one pass, making the edge banding corners smoother and more refined.
Scraping
Scraping knives on both sides remove ripple marks caused by trimming. The finished R corner matches the fine trimming result, making the upper and lower edges smoother and cleaner.
Polishing
Two high-speed rotating polishing wheels clean the processed board, making the edge banding section smoother and more attractive while helping keep polishing wheel wear even.
Applications
Suitable for customers who need complete automatic edge banding functions while controlling equipment footprint and shipping space.
Panel Furniture Edge Banding
Suitable for cabinet panels, furniture panels and other common panel furniture edge banding work.
Custom Furniture Workshops
Suitable for custom cabinet bodies, cabinet doors and daily edge banding of small-batch, multi-size panel workpieces.
Compact Production Spaces
Suitable for workshops with limited floor area that need a machine easier to install, move and arrange.
Container Loading Optimization
The machine can be stacked for container loading, helping reduce shipping-space pressure. Actual loading plans should be confirmed case by case.
Edge Banding Result
Technical Specs
The following specifications are based on confirmed HK268GY materials. Final configuration is subject to the actual machine and official proposal.
| Model | HK268GY | Work Form | Fully automatic |
|---|---|---|---|
| Overall Dimension | 5055*693*1200mm | Machine Weight | 1000KG |
| Sheet Thickness | 9-60mm | Minimum Sheet Width | Min.40mm |
| Minimum Workpiece Length | Min.150mm | Edge Band Width | 10-60mm |
| Edge Band Thickness | 0.35-3mm | Feed Rate | 16-22m/min |
| Voltage | 380V 50HZ | Total Power | 12.4kw |
| Rated Air Pressure | 6kg | Conveyor Motor | 2.2kw |
Factory Strength
Factory Exterior
SYUTECH factory exterior display.
Edge Banding Machine Workshop
Production area for small, medium and large edge banding machines.
CNC Nesting Machine Workshop
Production area for CNC nesting machines and nesting line solutions.
Six-Sided Drilling Workshop
Production area for six-sided drilling machines and line solutions.
Shanghai Exhibition Site
Exhibition team and equipment display.
Foshan Lunjiao Exhibition Site
Exhibition team and equipment display.
FAQ
What is HK268GY?
HK268GY is a compact automatic edge banding machine for panel furniture and custom furniture edge banding production.
What functions does it include?
It includes pre-milling, gluing, four-wheel pressing, end trimming, fine trimming, tracking, scraping and polishing.
What edge band range does it support?
The edge band width is 10-60mm, and the edge band thickness is 0.35-3mm.
What is the feed rate?
The confirmed workpiece feed rate is 16-22m/min.
What factories is it suitable for?
It is suitable for panel furniture factories, custom cabinet workshops and production sites that need a smaller footprint and easier machine movement.
Does the compact body reduce the function range?
HK268GY uses a compact structure while still covering the main edge banding processes including pre-milling, gluing and pressing, end trimming, fine trimming, corner tracking, scraping and polishing.
What are the panel size requirements?
Sheet thickness is 9-60mm, sheet width is 40mm or more, and minimum workpiece length is 150mm.
Is it convenient for shipping and container loading?
The compact machine body is lower than basic models and can be stacked for container loading, helping optimize shipping space.
